Category Archives: General

Devops Down Under 2010

I’ll be at Devops Down Under this weekend. This should be an amazing weekend, filled with talks which aim to help bridge the Developer and Sysadmin divide.

I’ll be giving a presentation entitiled Commit early, Deploy often. I’ll be talking about using package management to empower developers to deploy applications locally just as they would in production. This also means sysadmins can deploy using the exact same environment.

There are still a few tickets left, so if you are in Sydney this weekend and are either a developer or a sysadmin then make sure you come along.

Disclaimer: I’m also sponsoring the event.

Linux Australia Elections, Last chance to vote!

If you haven’t done so, please go and vote in the Linux Australia elections. If you aren’t a member then just join first, membership is free.

I’m running for the position of Treasurer, but you don’t need to vote for me since I’m running unopposed.

I’m running on a common platform with a group of other like minded individuals. You can find the details of the platform here.

The main reason I’m running is I believe that Linux Australia can achieve so much more than it does today. Linux Australia should not simply be a conduit for linux.conf.au.

I want to help turn Linux Australia into an organisation that is relevant to all of us. It should be an organisation that not only fosters and supports the community but also represents the community.

We should offer supportive services to our members, spread the FOSS message through the community as well as actively lobby government for the things we believe in.

Most importantly it is essential that we all become involved. The community is nothing without people to move it forwards. So I would encourage you to vote for

President James Turnbull
Vice President Lindsay Holmwood
Secretary Peter Lieverdink
Treasurer John Ferlito

Ordinary Committee Members
Alice Boxhall
Elspeth Thorne

Once you have finished voting, go and join the mailing lists and get involved.

Adding multiple database support to Cucumber

The Vqmetrics application needs to connect to two different databases. The first holds the videos, authors and their relevant statistics, while the second database holds the users, monitors and trackers.

We do this by specifying two databases in config/database.yml.

development:
  database: vqmetrics_devel
  < <: *login_dev_local

vqdata_development: &VQDATA_TEST
  database: vqdata_devel
  <<: *login_dev_local

So by default the vqmetrics_devel database will be used. When we need to specify a model where we need to connect to the vqdata_devel database we use

class Video < ActiveRecord::Base
  establish_connection "vqdata_#{RAILS_ENV}"
end

and for migrations that need to connect to this database we do the following.

class InitialSetup < ActiveRecord::Migration
  def self.connection
    Video.connection
  end
end

This setup works really well. However recently I moved this application to using Cucumber for testing. Tests worked fine the first time they are run but not the second time.

I discovered that the transaction on the second database where not being rolled back as they should be. Cucumber only sets up the first database for roll back by using

ActiveRecord::Base.connection

where it should be rolling them all back by looping through

ActiveRecord::Base.connection_handler.connection_pools.values.map {|pool| pool.connection}

I’ve filed a bug at lighthouseapp.

Building a Private PPA on Ubuntu

One of the things I love about the Ubuntu project and launchpad is the Personal Package Archive. PPAs make it so simple and easy to backport packages. The only problem with PPAs is that they are public. I had a need to be able to host some private internal packages as well as squid with SSL support, which you can’t distribute in binary form due to licensing restrictions.

Basically I wanted to create the equivalent of an Ubuntu PPA service running on our own servers so we could place it behind our firewall. This post is basically the process I followed to integrate rebuilld and reprepro to replicate a PPA setup.

So first up install reprepro

aptitude install reprepro

next we need do create a reprepro repository

mkdir -p /srv/reprepro/{conf,incoming,incomingtmp}

Now we need to tell reprepro which distributions we care about. Create /srv/reprepro/conf/distributions with the following contents

Suite: hardy
Version: 8.04
Codename: hardy
Architectures: i386 amd64 source
Components: main
Description: Local Hardy
SignWith: repository@inodes.org
DebIndices: Packages Release . .gz .bz2
DscIndices: Sources Release .gz .bz2
Tracking: all includechanges keepsources
Log: logfile
  --changes /srv/reprepro/bin/build_sources

Suite: intrepid
Version: 8.10
Codename: intrepid
Architectures: i386 amd64 source
Components: main
Description: Local Intrepid
SignWith: repository@inodes.org
DebIndices: Packages Release . .gz .bz2
DscIndices: Sources Release .gz .bz2
Tracking: all includechanges keepsources
Log: logfile
  --changes /srv/reprepro/bin/build_sources

Suite: jaunty
Version: 9.04
Codename: jaunty
Architectures: i386 amd64 source
Components: main
Description: Local Jaunty
SignWith: repository@inodes.org
DebIndices: Packages Release . .gz .bz2
DscIndices: Sources Release .gz .bz2
Tracking: all includechanges keepsources
Log: logfile
  --changes /srv/reprepro/bin/build_sources

I also like to create reprepro options file to setup some defaults, edit /srv/reprepro/conf/options

verbose
verbose
verbose
verbose
verbose

Next we need to setup an incoming queue so that we can use dput to get the source packages into reprepro,
vi /srv/reprepro/conf/incoming

Name: incoming
IncomingDir: incoming
Allow: hardy intrepid jaunty
Cleanup: on_deny on_error
Tempdir: incomingtmp

The repository is now ready to go. So now we can setup apache. Edit /etc/apache/sites-enabled/pppa


    ServerName packages.inodes.org
    DocumentRoot /srv/reprepro

and we should also configure our sources.list to use these repositories, edit /etc/apt/sources.list

# Sources for rebuildd
deb-src http://packages.inodes.org hardy main
deb-src http://packages.inodes.org intrepid main
deb-src http://packages.inodes.org jaunty main

Next we want to setup our dput.cf to make the magic happen to get the source packages into the archive, edit ~/.dput.cf

[DEFAULT]
default_host_main = notspecified

[local]
fqdn = localhost
method = local
incoming = /srv/reprepro/incoming
allow_unsigned_uploads = 0
run_dinstall = 0
post_upload_command = reprepro -V -b /srv/reprepro processincoming incoming

So now we can do the following

apt-get source squid3
cd squid3*
dch -i # increment version number
dpkg-buildpackage -sa -S
cd ..
dput local *changes
aptitude update
apt-get source squid3

So when you run dput, first it copies the source package files to /srv/reprepro/incoming and then it gets reprepro to process it’s incoming queue. This means that the source package is now sitting in the repository.
So the second apt-get source should have downloaded the source package from our local repository which is exactly what rebuildd will do before it tries to build it.

Next step is to setup rebuildd so that it builds the binary packages and installs them into the repository.

aptitude install rebuildd

Setup so it runs out of init.d and the releases we care about, edit /etc/default/rebuildd

START_REBUILDD=1
START_REBUILDD_HTTPD=1
DISTS="hardy intrepid jaunty"

Now when a source package is uploaded into the repository we want to kick off rebuildd to build the package. We can do this through the reprepro log hooks. You’ll notice in the conf/distributions above the following lines.

Log: logfile
  --changes /srv/reprepro/bin/build_sources

This script will be run any time a .changes file is added to the repository. Create /srv/reprepro/bin/build_sources

#!/bin/bash

action=$1
release=$2
package=$3
version=$4
changes_file=$5

# Only care about packages being added
if [ "$action" != "accepted" ]
then
	exit 0
fi

# Only care about source packages
echo $changes_file | grep -q _source.changes
if [ $? = 1 ]
then
	exit 0
fi

# Kick off the job
echo "$package $version 1 $release"  | sudo rebuildd-job add

This script basically checks the right type of package is being added. Then it calls rebuildd-job to ask for that specific package and version to be built for that Ubuntu release.

Now the first thing that rebuildd does is download the source for the package. However we need to update the sources first since our server doesn’t know there are new files in the repository yet. So edit /etc/rebuildd/rebuilddrv an change

apt-get -q --download-only -t ${d} source ${p}=${v}

to

source_cmd = /srv/reprepro/bin/get_sources ${d} ${p} ${v}

and create /srv/reprepro/bin/get_sources with

#!/bin/bash

d=$1
p=$2
v=$3

sudo aptitude update >/dev/null
apt-get -q --download-only -t ${d} source ${p}=${v}

By this stage we have rebuildd building packages but we need to make sure they get re-injected back into the repository. We can do this with a post script. Edit /etc/rebuildd/rebuilddrc

post_build_cmd = /srv/reprepro/bin/upload_binaries ${d} ${p} ${v} ${a}

and create /srv/reprepro/bin/upload_binaries

#!/bin/bash

d=$1
p=$2
v=$3
a=$4

su -l -c "reprepro -V -b /srv/reprepro include ${d} /var/cache/pbuilder/result/${p}_${v}_${a}.changes" johnf

Now the su is in there because rebuildd needs to be able to access the GPG passphrase to sign the repository with. So rather than have a passphrase-less key we make sure that gpg-agent is running by adding the following to your .profile.

if test -f $HOME/.gpg-agent-info &&    kill -0 `cut -d: -f 2 $HOME/.gpg-agent-info` 2>/dev/null; then
	GPG_AGENT_INFO=`cat $HOME/.gpg-agent-info`
	export GPG_AGENT_INFO
else
	eval `gpg-agent --daemon`
	echo $GPG_AGENT_INFO >$HOME/.gpg-agent-info
fi

GPG_TTY=`tty`
export GPG_TTY

So that’s it you now have your own personal PPA. Just in case you had fallen asleep. Here is a little script I wrote so you can auto build the source packages for each release you care about in one go.

#!/bin/bash

set -e

RELEASES="hardy intrepid jaunty"

if [ ! -f debian/changelog ]
then
	echo "This isn't a debian repo"
	exit 1
fi

# Check for changes
if [ `bzr st | wc -l` != "0" ]
then
	echo "You have uncommitted changes!"
	exit 1
fi

if [ -d ../tmpbuild ]
then
	echo "The tmpbuild dir exists"
	exit 1
fi

bzr export ../tmpbuild
cp debian/changelog ../tmpbuild.changelog
cd ../tmpbuild

PACKAGE=`head -1 debian/changelog | awk '{print $1}'`
VERSION=`head -1 debian/changelog | awk '{print $2}' | sed -r -e 's/^(//;s/)$//'`

for release in $RELEASES
do

	sed -r -e "1s/) [^;]+; /~${release}) ${release}; /" ../tmpbuild.changelog > debian/changelog
	head -1 debian/changelog
	dpkg-buildpackage -S -sa
	dput local ../${PACKAGE}_${VERSION}~${release}_source.changes
done

cd ..
rm -rf tmpbuild

So the above documentation is a bit of a brain dump on what I’ve been working on for the past 2 days and I’m sure I’ve left some bits out. So please give me any feedback you have in the comments.

Mac OS X L2TP VPN to Cisco IOS

Just spent a couple of hours trying to get a Mac OS X laptop connected to a Cisco IOS IPSEC/L2TP server. The existing configuration worked fine for windows and linux servers but the Mac just refused to establish a connection. The Cisco logs contained the usual cryptic message.

Dec 16 16:53:47.955: IPSEC(validate_proposal_request): proposal part #1,
  (key eng. msg.) INBOUND local= 117.53.171.241, remote= 124.171.30.131,.
    local_proxy= 117.53.171.241/255.255.255.255/17/1701 (type=1),.
    remote_proxy= 124.171.30.131/255.255.255.255/17/1701 (type=1),
    protocol= ESP, transform= esp-3des esp-sha-hmac  (Transport-UDP),.
    lifedur= 0s and 0kb,.
    spi= 0x0(0), conn_id= 0, keysize= 0, flags= 0x800
Dec 16 16:53:47.955: Crypto mapdb : proxy_match
    src addr     : 117.53.171.241
    dst addr     : 124.171.30.131
    protocol     : 17
    src port     : 1701
    dst port     : 49561
Dec 16 16:53:47.955: map_db_find_best did not find matching map
Dec 16 16:53:47.955: IPSEC(validate_transform_proposal): no IPSEC cryptomap exists for local address A.B.C.D

After much googling I discovered that the problem was dst port: 49561 . Unlike most other L2TP clients the Mac uses a random source port for the L2TP part of the connection. Most others use 1701 for source and destination.

So relaxing this

ip access-list extended L2TP
 permit udp host 117.53.171.241 eq 1701 any eq 1701

to this

ip access-list extended L2TP
 permit udp host 117.53.171.241 eq 1701 any

solved the problem.

It would now normally be the time for me to rant about how IPSEC has to be one of the most badly implemented protocols by all vendors and how getting two different implementations to talk to each other always takes a minimum of 2 hours even if you’ve done it before but it would just be too exhausting.
